XZ210 Horizontal Directional Drill

(HDD)

XCMG Foundation Construction Machinery Co.; Ltd.

Product Model:XZ210 Horizontal Directional Drill (HDD)

Manufacturer:XCMG Foundation Construction Machinery Group Co.; Ltd.

XZ210 HDD structure compact, high performance, full-featured, hydraulic pilot control, sliding rack and pinion, the main performance parameters and control technology has reached the international advanced level. Hydraulic systems, power systems, running system, and the main components are made of domestic first-class brand products, good performance, good reliability.

I  Features Introduction

1.Hydraulic pilot control, with comfortable handling and flexible regulation, first-class brand of hydraulic components to ensure the reliability of the whole hydraulic system.

2.Gear rack thrust/pull design insures operation. Floating carriage can protect the screw thread of the rods.

3.High-speed sliding systems, variable motor to achieve high and low carriage sliding change, increasing the ability to adapt the drilling rig working conditions, improve the efficiency of the drilling rig construction

4.Stable chassis support, using the classic H-beam structure, high quality rubber track, breaststroke leg structure, provide a strong guarantee for the stability of the whole construction.

5 .Support the diverse needs of customers, the machine can be increased with the automatic (semi-automatic) drill pipe handling device, automatic anchoring system, cab, air conditioning wind,  freezing mud, mud washing and other devices, can also optional more environmentally friendly.

II Technology Introduction

1.Hydraulic System

Using a hydraulic pilot control, hydraulic components are domestic first-class brand. Most important parts of hydraulic system are made of leading domestic and foreign products, good performance, good reliability. Five pumps coordinated action to complete the working, a reasonable allocation of engine power.

Hydraulic system pressure              21MPa;

Fuel tank volume                     230L;

2.Engine System

Engine type                           6BT5.9-C150

Rated power                            110kW

Rated speed                             2300 r/min

Maximum engine torque             560 N·m /(1400r/min)

3.Chassis

XZ210 use classic H-beam structure, high quality rubber track, site adaptability, high reliability, breaststroke leg structure, large cylinder support, good stability, Eaton walking gear, stable performance, walking speed can reach 2.2km / h.

Track width                             2090 mm

Rubber Track Width                    320 mm

Tread                                      1910 mm

Supporting wheels Quantity              2×6

Driving force                              68000N

Gradeability                               30%

Walking speed                           2.2km/h

Grounding pressure                       63kPa

Overall working weight                  8.5t

4.Carriage

The drilling rig completed by rack and pinion sliding action, carriage floating device can effectively protect the drill thread, variable-speed motor to achieve sliding.

Max. Thrust/Pullback force                    245 kN

Max. Thrusting /pulling speed                32 m/min

Max Rotation torque                        6350 N·m

Max. Rotation speed                        160 r/min

Max. Walking distance of carriage          3900 mm

  1. 5.Mud Systerm

250L mud pump system according to the construction, to provide powerful construction, large flow, ensure the smooth construction.

Max. Mud pump flow                     250L/min

Max. Mud pump pressure                  80bar

6.Console and Cab(Optional)

Collaboration with professional bodies, Cab, console ergonomics analysis and research, fully considered during the operation operator comfort and instrument layout is reasonable, can be increased with the cab, air conditioner, reduce labor intensity, improve the efficiency of the operator.

Size                                    1200×1050×1600mm

Air conditioner refrigeration                 4600W

Air conditioner heating                     5000W(发动机冷却液85℃以上)when the engine cooling fluid is more than 85℃



  1. Pipe Loader(Optional)

.Machine can option configuration with the automatic semi-automatic pipe loader, used rotating structure to achieve handling drill semi-automatization, also can option automatic full-automatic pipe loader, to achieve handling drill automation. Optional Full-automatic pipeloader, Drilling box can accommodate 48 piece of φ60×3000 drill pipes, this system can add pipe capacity for long distance construction Efficient automation construction, reduce construction costs and labor intensity.

Note:This Full-automatic pipeloader use φ60×3000 drill pipes!

8.Anchor(Optional)

Main machine with normal anchor, also can option automatic anchor help push and drill, highly automated and great power, reduce labor intensity.

9.Drill and Drilling Tools

Other accessories of XZ210 horizontal directional drill rig are configured as follows:

Name Type Form Specification Remarks
Drill rods Monolithic



¢60mm×3m XCMG
Welded type
Drilling Tools

Reamer

Squeezed style ¢200mm XCMG
¢300mm
¢400mm
¢500mm
¢600mm
¢700mm


Runner type

¢200mm
¢300mm
¢400mm
¢500mm
¢600mm
¢700mm
Accessories Drill guide 60
Starting lever 60
钻具

Drilling Tools

辅件

Accessories

Guide plate 60
Torques 60
L-nut 60
Male slider 60
Female slider 60
Splitter 20t
Connect 60
Mud system Mud Mixing System 2 cbm Shanghai
3 cbm
Instrument

Guide Instrument

Navigator E/ET

XCMG

F2 US DCI
F5
SE
Detector 8100 Radiodetection



III.Main technical parameters

Item Parameter
Engine Manufacturers Dongfeng Cummins
Model 6BT5.9-C150
Rated Power 110 kW / 2300 r/min
Thrust/Pullback Type Pinion and rack drive
Max Thrust/Pullback force 245/245 kN
Max Thrust/Pullback speed 32 m/min
Rotation Type two motor
Max Rotation torque 6350 N·m
Max. Rotation speed 160 r/min
Rods Diameter × Length Φ60×3000 mm×mm
Mud pump Max Flow rate 250 L/min
Max pressure 8 MPa
Weight / 8500 kg



IV.Main part configuration

Name

Manufacture factory

Engine Dongfeng Cummins
Main Pump Permco
Auxiliary Pump Permco
Rotary Motor Eaton
Reduction Box XCMG
Hand Shank Eaton/ XCMG
 Hydraulic tube XCMG
Hydraulic cylinders XCMG
 Track reducer Eaton/ XCMG



V.Transport Program

xcmg xz210 hdd machine

xcmg xz210 hdd machine

The machine transportation dimension           5900×2250×2400mm

Shiping weight(free of drill and drilling tools                  8.5t

Cab configuration, automatic anchoring, automatic

Overall dimensions (standard)                5900×2270×2400mm

Handling drill equipment (including 48 drill), Weight     10t

VI.Accompanied Attached Documents

XZ210 HDD machine start when accompanied by the packing list, include the following technical documents

Product Certificate

Product Manual

Engine Specification

Engine Warranty

Mud Pump Instruction Manual

Packing List (including wearing parts and spare parts inventory, vehicle tools inventory, shipping list with items)

VII. Attached Equipment

Items Optional XZ210 Optional
Engine 6BT5.9-C150  110kW
Cold start /
Anchoring device Simple anchor
Dual automatic anchor /
Mud system  Mud antifreeze /
Mud Cleaning /
Pipe Loader Semi-automatic gripper /
Automatic shuttle arm /
Cab Simple machine tent
Cab and air conditioner /

√-Normal  □-Optional

xcmg hdd machine xz210

xcmg hdd machine xz210

Advances in technology design, we can not change the product effective notice to you, please forgive me!
